POLAR (w/ POLAR 4)

POLAR (w/ POLAR 4)

Specifications

POLAR 2POLAR 4

Number of Microphone Preamps

24

Phantom Power

Yes, 48VYes, 48V

Instrument Inputs

24

Line Inputs

24

Enhance Switches

24

Line Outputs

24

Headphone Outputs

12

MIDI

NoMIDI In / Midi Out - 8 Pin DIN

Loopback

YesYes

Connectivity

USB Type-CUSB Type-C

Protocol

USB 2.0USB 2.0

Form Factor

DesktopDesktop

Simultaneous I/O

4 x 4 (including Loopback inputs)6 x 6 (including Loopback inputs)

A/D Resolution

24-bit/192 kHz24-bit/192 kHz

Bus Powered

Yes (960mA)Yes (960mA)

Supported Sample Rates

44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

Bundled Software

POLAR Control App, St. James Plugin Suite, Ableton Live Lite, ReLab LX480 Essentials Reverb, Melodyne EssentialPOLAR Control App, St. James Plugin Suite, Ableton Live Lite, ReLab LX480 Essentials Reverb, Melodyne Essential

Weight

0.64kg0.93kg

Dimensions

170 x 64 x 115 (mm)230 x 64 x 115 (mm)
